OAK-D HD Camera Development Kit, OpenCV AI Machine Vision Kit.

OAK-D OpenCV AI Machine Vision Kit

Depth Measuring / Image Recognition & Location / Safety & Security Monitoring

Intelligent Driving / Robotics / Object Tracking

Specifications :

DEPTH MEASURING RANGE	0.2 ~ 9 m
DEPTH CAMERA	global shutter
RGB CAMERA	12MP
MAX FRAMERATE	60fps (RGB), 200fps (Depth)
AI CHIP	Intel Myriad X 4TOPS computing performance
VIDEO PLUG FLOW	4K 30 fps H.265 plug flow
CONNECTOR	USB3.0 Type-C
EXPANSION INTERFACES	GPIO, SPI, UART
NN PLATFORM SUPPORT	all platforms
POWER CONSUMPTION	avg 2.5W
DEVELOPMENT LANGUAGE	Python, C++
ECLOSURE	aluminum enclosure
WEIGHT	115g

Powerful Computing Performance

The OAK Provides Up To 4TOPS Computing Performance,

10 Times Of OpenMV, 40 Times Of Raspberry Pi 4B

Camera Specifications

Use Free Neural Networks Or Create Your Own

The OAK adopts Myriad X for binocular depth calculating as well as AI neural inference, then providing direct outputs like target coordinates, IMU data, recognition results, and so on. More other functions can be achieved by calling the API, which allows you to build your own system easier.

Extensive Applications

The OAK Can Be Widely Used Thanks To Its Rich Functions And Technologies,

It Will Upgrade Your Project To The Next Level By Enabling The Computer Vision Feature

Intelligent traffic Intelligent driving

Detection and recognition for motor vehicles, Recognizing and ranging around vehicles and road conditions, recognizing the driver status and providing intelligent assistance.

non-motor vehicles, pedestrians, traffic signs, traffic events...

Intelligent safety & security Robotics

The neural network keeps learning new sudden human body Used on industrial robots field, enabling robot functions like target identification, positioning, size measuring, binocular depth mapping, navigation...

featuresand event accidents, providing intelligent detection

and givingalarm for human abnormal behaviors and accidents.
