• WisBlock Core Module

RAK3372 is a low-power long-range transceiver module for LoRa and LoRaWAN applications based on STM32WLE5CC chip.

  • This version is for our WisBlock Base Boards which allows you to add WisBlock sensor and IO modules by just plugging them into the Base Board together with the RAK3372.
  • The firmware of the RAK3372 is based on RAKwireless Unified Interface V3 (RUI3) that allows you create different functionalities using RUI3 APIs. It provides an easy-to-use, small-size, low-power solution for long-range wireless data applications. This module complies with Class A, B, & C of LoRaWAN 1.0.3 specifications. It can easily connect to different LoRaWAN server platforms like TheThingsNetwork (TTN), Chirpstack, Helium, etc. It also supports LoRa Point-to-Point (P2P) communication mode which helps you in implementing your own customized long-range LoRa network quickly.
  • It can work as a stand alone device by creating custom firmware via RUI3 APIs or can be deployed as a LoRA modem with an external host like a microcontroller or microprocessor that configures and send commands to the module using AT and Binary commands via a UART interface.

Features:

  • LoRa module for Smart City, Smart Agriculture, Smart Industry
  • Temperature range: -40 °C to +85 °C
  • Supply voltage: 2.0 ~ 3.6 V
  • Frequency range: 150 MHz to 960 MHz
  • Low-Power Wireless Systems with 7.8 kHz to 500 kHz Bandwidth
  • Ultra-Low Power Consumption 1.69 μA in sleep mode
  • Core: ARM 32-bit Cortex – M4 with MPU Up to 256 KB flash memory with ECC
  • 64 KB RAM
  • RUI3 API Compatible
  • AT and Binary Commands Support
  • Supported bands: (EU433, CN470, RU864, IN865, EU868, AU915, US915, KR920, and AS923)
  • Size 20 x 30 mm

Documentation:

Package Includes:

  • 1 x RAK3372
  • 1 x LoRa Antenna


Write a review

Please login or register to review

WisBlock Core Module

  • Brand: Rakwireless
  • Product Code:NR-RAK-WisBlock-Core-Module
  • Reward Points:16
  • Availability:In Stock
  • रo 1,565.00

  • Price in reward points:1565

  • 10 or more रo 1,550.00
  • 20 or more रo 1,535.00
  • 50 or more रo 1,525.00
  • 95 or more रo 1,510.00
