RAK17000 is a WisBlock DC motor driver module based on Texas Instruments DRV8833. It can control one stepper motor or two DC motor with the module driver DRV8833 from TI. It can either use the WisBlock Base voltage supply to power the motor or an external voltage supply.

Features:

• Drive two DC motors or one stepper motor
• Wide power supply voltage range: 2.7 to 10.8V
• Output current control
• 2.54mm Jumper choice power supply
• Module size: 25X35mm

Documentation

• RAK17000 Quick Start Guide
• Datasheet
• WisBlock Quick Start Guide
• WisBlock Sensor Tutorial

Examples:

• For WisBlock Core RAK4630:
• Sample Code: DC Motor Contro1
• Sample Code: Stepper Motor Control
• For WisBlock Core RAK11200:
• Sample Code: DC Motor Control
• Sample Code: Stepper Motor Control
• For WisBlock Core RAK11310:
• Sample Code: DC Motor Control

Package Includes:

• 1 x RAK17000 WisBlock Motor Control Module Texas Instruments DRV8833
