• Pololu 2599 Magnetic Encoder Disc for Micro Metal Gearmotors, OD 7.65 mm, ID 1.0 mm, 12 CPR
These magnetic discs can be used with our micro metal gearmotors with extended motor shafts as part of a quadrature encoder system that offers 12 counts per revolution. They are 2 mm thick with an outer diameter of 7.65 mm and an inner diameter of 1.0 mm. Appropriate Hall Effect sensors, such as those in our magnetic encoder pair kit with top-entry connector for micro metal gearmotors, are required to complete the system.

Specifications:
  • Size: 7.65 mm outer diameter × 2 mm thick (1.0 mm ID)
  • Weight: 0.3 g
  • Poles: 6
  • Encoder resolution: 12 CPR1
Documents:
Warranty:
  • Warranty will not apply if Product fails or is damaged after delivery to you due to accident, abuse or misuse.
Package Includes:
  • 1 x Pololu 2599 Magnetic Encoder Disc for Micro Metal Gearmotors, OD 7.65 mm, ID 1.0 mm, 12 CPR

Write a review

Please login or register to review

Pololu 2599 Magnetic Encoder Disc for Micro Metal Gearmotors, OD 7.65 mm, ID 1.0 mm, 12 CPR

  • Brand: Pololu
  • Product Code:Pololu-2599-Encoder-Disc
  • Reward Points:1
  • Availability:In Stock
  • रo 65.00

  • Price in reward points:65

  • 500 or more रo 63.00
