MAX745 Switch-Mode Lithium-Ion Battery-Charger,for 1-4 in series 4.2V/4.35V battery charge.

single cell voltage adjustment range: 4.1-4.4V,covering 4.2 / 4.35V battery
Charge current adjustment range (default) 0-1.8A (0-3.6A) potentiometer adjustment.default max.current is 1.8A.
Input voltage: 6-20VDC (Input volatge higher than battery volatge 2V)
Default setting :1S (4.2V)
Size:36*32*9mm
Charging interface: Red LED indicator,when charing is Red,Fully charged light is off.


Typical Operating Circuit123

Write a review

Please login or register to review

MAX745 1-4 Pack Lithium Battery Charging Board

  • Product Code:PRC-MAX745-LiPo-Charger
  • Reward Points:16
  • Availability:Discontinued
  • रo 1,641.00

  • Price in reward points:1641
