The Liquid Level Sensor is designed with industry-grade standards, for monitoring water level, oil level, and other mild-corrosive liquid levels. It incorporates stainless steel and insulated rubber, is IP68 rated, suitable for application in severe environments and uses the RS485 Modbus-RTU Protocol.

The liquid level sensor measures the height of the liquid and converting it to the Modbus-RTU protocol. It works with a data logger or other devices that support the RS485 Modbus-RTU protocol.

The liquid level sensor has a built-in high-performance and highly sensitive silicon piezoresistive core. The internal chip converts the sensor's millivolt signal into a standard protocol which can be connected to a computer, control instrument, or PLC.

It's small-size, lightweight, and easy to install. It has a stainless steel sealing structure that can work in a corrosive environment. The sensor has high anti-vibration and anti-impact performance. It can be widely used in process control, aviation, aerospace, automobile, medical equipment, HVAC, and other applications.

Features:

  • Strong anti-interference and long-term stability
  • Anti-corrosion  material,  excellent  anti-corrosion  performance, and durable
  • Anti-blocking design, easy to clean
  • Modbus-RTU  RS485  protocol,  it  can  be  used  with a display  device, PLC, inverter, recorder, and other instruments
  • The  shell  is  made  of  stainless  steel  and  durable,  and  with  waterproof cable, safe to use
Specifications:
  • Measurement Range: 0 ~ 5 meters
  • Cable Length: 5.3 meters
  • Output Signal: RS485 Modbus-RTU Protocol
  • Accuracy: ± 0.25%F.S
  • Zero Temperature Drift: ± 0.03%F.S/℃
  • Sensitivity Temperature Drift: ± 0.03%F.S/℃
  • Long-term Stability: ≤0.2%F.S/year
  • Response Time: 5ms( (≤90%F.S)
  • Measurement Liquid: Slight corrosive liquid (water, edible oil, etc.)
  • Power Supply: 11-30V DC
  • Overload Capacity: 200%F.S
  • Compensation Temperature: -10℃ ~ +70℃
  • Medium Temperature: -40℃ ~ +80℃
  • Storage Temperature: -40℃ ~ +85℃
  • Material: 304 stainless steel shell, 316L stainless steel core, special rubber-insulated cable.
  • IP Rating: IP68
  • Device Weight: 670g
  • Certifications: CE, FCC, RoHS

Applications:

  • Reservoir detection
  • Pool pump station
  • River monitoring
  • Marine monitoring
  • Lake monitoring
  • Sewage treatment
  • Deep well level monitoring
  • Tank level monitoring

Documents:

Package Includes:

  • 1 x Industrial Liquid Level Sensor MODBUS RS485 Aviation Connector
