PIM221
- 1 x 24V @ 2A relay (NC and NO terminals)
- 3 x 12-bit ADC @ 0-24V (ADS1015) (±2% accuracy)
- 3 x 24V tolerant buffered inputs
- 3 x 24V tolerant sinking outputs
- 3.5mm screw terminals
- SPI pins broken out
- Automation pHAT pinout
- Compatible with all 40-pin header Raspberry Pi models
- Python library
- Female header and broken out pins require soldering
-
PIM213
- 3 x 24V @ 2A relays (NC and NO terminals)
- 3 x 12-bit ADC @ 0-24V (±2% accuracy)
- 3 x 24V tolerant buffered inputs
- 3 x 24V tolerant sinking outputs
- 15 x channel indicator LEDs
- 1 x 12-bit ADC @ 0-3.3V
- 3.5mm screw terminals
- Power, Comms, and Warn! LED indicators
- SPI, TX (#14), RX (#15), #25 pins broken out
- Automation HAT pinout
- Compatible with all 40-pin header Raspberry Pi models
- Python library
- Schematic
- Comes fully assembled (broken out pins require soldering)
Note:
- We recommend you use a set of brass M2.5 standoffs with Automation HAT to avoid pins contacting the HDMI port if the HAT is pushed down
- Loads for the buffered outputs should be switched on the ground side, i.e. 12/24V (from supply) -> load -> output terminal -> ground (from supply)
- The relays can tolerate up to 2A each and should be switched on the high side
- The sinking outputs can sink a maximum 500mA total across the 3 outputs, so if you use a single channel you can sink the whole 500mA across it.
- The accuracy of the ADC is ±2%.
- Do not use to switch mains voltages!
Package Includes:
- 1 x Automation pHAT
Automation pHAT
- Brand: Pimoroni
- Product Code:PIM-Automation-pHAT
- Reward Points:47
- Availability:In Stock
-
रo 4,724.00
- Price in reward points:4724
-
- 3 or more रo 4,686.00
- 5 or more रo 3,843.00
- 8 or more रo 3,812.00
- 10 or more रo 3,254.00
- 22 or more रo 3,228.00
- 45 or more रo 3,202.00
