• Arduino MKR WiFi 1010 IoT Board

The Arduino MKR WiFi 1010 is the easiest point of entry to basic IoT and pico-network application design. Whether you are looking at building a sensor network connected to your office or home router, or if you want to create a BLE device sending data to a cellphone, the MKR WiFi 1010 is your one-stop-solution for many of the basic IoT application scenarios.

Specifications:

  • Microcontroller SAMD21 Cortex®-M0+ 32bit low power ARM MCU
  • Radio module u-blox NINA-W102
  • Board Power Supply (USB/VIN) 5V
  • Secure Element ATECC508
  • Supported Battery Li-Po Single Cell, 3.7V, 1024mAh Minimum
  • Circuit Operating Voltage 3.3V
  • Digital I/O Pins 8
  • PWM Pins 13 (0 .. 8, 10, 12, 18 / A3, 19 / A4)
  • UART - 1
  • SPI - 1
  • I2C - 1
  • Analog Input Pins 7 (ADC 8/10/12 bit)
  • Analog Output Pins 1 (DAC 10 bit)
  • External Interrupts 8 (0, 1, 4, 5, 6, 7, 8, 16 / A1, 17 / A2)
  • DC Current per I/O Pin 7 mA
  • CPU Flash Memory 256 KB (internal)
  • SRAM 32 KB
  • EEPROM no
  • Clock Speed 32.768 kHz (RTC), 48 MHz
  • LED_BUILTIN 6
  • USB Full-Speed USB Device and embedded Host
  • Length 61.5 mm
  • Width 25 mm
  • Weight 32 gr.

Documents:

Package Includes:

  • 1 x Arduino MKR WiFi 1010 IoT Board



Write a review

Please login or register to review

Arduino MKR WiFi 1010 IoT Board

  • Brand: Arduino
  • Product Code:Ard-MKR-WiFi-1010
  • Reward Points:35
  • Availability:In Stock
  • रo 3,526.00

  • Price in reward points:3526

  • 50 or more रo 3,524.00
  • 150 or more रo 3,358.00
