This H-Bridge Motor Shield based on 8 N-channel MOSFET IRF3205S and 4 pcs half-bridge motor controller IR2104, to build 2 H-bridge. With this shield, you can control two DC motors with a max current of up to 8A with 22v voltage at the same time. Also, you can control the motor direction by the logic 0 or 1 with digital pin and speed by the PWM PIN of your MCU, like Arduino. And we support Screw interface, it is easy to connect to the motor and power.
  • Based on those Maduino solutions, Makerfabs can also help to customize those boards with customer’s special requests. Contact [email protected] for detailed info and further discussion. For more detail, you can read our PCB Design and PCBA Turnkey Solution.
Features:
  • Operating Voltage: 6- 22V
  • Continuous output current: up to 8 Amps
  • Peak output current: 15 Amps
  • PWM Duty: 0~99%
  • Dimension: 68mm x53mm x 23mm
Documents :
Package Includes:
  • 1 x H-Bridge Motor Shield
