Sixteen LEDs around the Edge of the Board

The TinyShield 16 Edge LEDs allows some cool and easy LED indications using only five I/O signals. The 16 LEDs are mounted around the outside of the board, and can easily be seen even when the LED board is in the middle of a TinyShield stackup. The LEDs are arranged using Charlieplexing, which is a technique to allow for control of multiple LEDs using fewer I/O signals.


Specifications:
  • 16 Side Mounted Amber LEDs around the board of the Board
  • Ultra compact size and weight (smaller than a US Quarter!)
  • Square Version: 20mm x 20mm (.787 inches x .787 inches)
  • Circular Version: 20mm (.787 inches) diameter
  • Max Height (from lower bottom TinyShield Connector to upper top TinyShield Connector): 5.11mm (0.201 inches)
Support:



Write a review

Please login or register to review

TinyShield 16 Edge LEDs

  • Brand: TinyCircuits
  • Product Code:TinyC-Shield-16-Edge-LED
  • Reward Points:12
  • Availability:In Stock
  • रo 1,193.00

  • Price in reward points:1193

  • 10 or more रo 1,182.00
  • 20 or more रo 1,172.00
  • 50 or more रo 1,162.00
