Features:
  • EFL: 1.3mm F.No: 2.2
  • View Angle: D85.6°/H72.9°/V57.7°
  • Distortion: <1.5%
  • Image quality: >=200LW/PH(AT=0.13m)
  • Focusing Range: 0.065m-∞(AT=0.13m)
  • Chip Type: OV7251-G04A-1E(COB)
  • Build-in 650nm IR block filter
  • Array Size: 640*480 Lens Size: 1/7.5 inch
  • 3x3μm pixel with Omnipixel3-GS technology
  • Support putput format:8/10-bit RAW
  • Support 2x2 monochrome binning
  • One-lane MIPI serial output interface
  • Active array size: 640*480
  • Output interface:1-lane MIPI/LVDS serial output output formats: 10-bit RGB RAW or BW
  • Maximum image transfer rate: 640*480: 100 fps
  • Camera connector: BBR13-24K6417, Board connector: BBR43-24KB533

Applications:
  • Cellular phones
  • Digital still cameras (DSC)
  • Digital video camcorders (DVP)
  • PC multimedia
  • Tablets
Package Includes:
  • 1 x Arducam U6070 1/7.5 inch CMOS OV7251 Global Shutter Standalone Camera UC-7251-716
Sensor Specifications
Sensor type CMOS OV7251
Sensor size 1/7.5''
Lens Specifications
Field of View D85.6°/H72.9°/V57.7°

Write a review

Please login or register to review

Arducam U6070 1/7.5 inch CMOS OV7251 Global Shutter Standalone Camera UC-7251-716

  • Brand: ArduCAM
  • Product Code:ArdC-U6070-Standalone-Cam
  • Reward Points:14
  • Availability:In Stock
  • रo 1,369.00
  • रo 1,198.00

  • Price in reward points:1426

  • 20 or more रo 1,358.00
  • 50 or more रo 1,364.00
  • 100 or more रo 1,346.00
