2 Mega pixel Camera Module MT9D111 JPEG Out.
Features:
- Digital Clarity CMOS imaging technology;
- Ultra low-power, low-cost, progressive scan;
- 2-megapixel resolution (1,600H x 1,200V);
- 1/3.2-inch optical format;
- 15 frames per second (fps) at full resolution;
- Real-time JPEG encoder;
- Integrated microcontroller for flexibility;
- On-chip image flow processor for single-chip camera module;
- On-chip auto focus with configurable GPIO interface;
- Mechanical shutter support;
- Numerous automatic functions for on-the-fly image correction and enhancement;
- Fully automatic Xenon- and LED-type flash support,including fast exposure adaptation;
- On-chip, 10-bit analog-to-digital converter;
- JPEG 4:2:2 and 4:2:0 output.
Documents:
- User Guide – Arducam 2MP MT9D111 CS Camera Breakout Board
- User Guide – Arducam 2MP MT9D111 M12 Camera Breakout Board
- Sensor Datasheet – MT9D111
- Arducam Documentation – Arducam Camera Breakout Board
Package Includes:
-
B0009:
- 1 x 2 Mega pixel Camera Module MT9D111
- 1 x HQ lens
-
B0010:
- 1 x 2 Mega pixel Camera Module MT9D111 JPEG Out
ArduCam B0009/B0010 Mega pixel Camera Module MT9D111 JPEG Out with optional HQ lens
- Brand: ArduCAM
- Product Code:ArdC-2-MP-Cam-Module-MT9D111
- Reward Points:17
- Availability:In Stock
- रo 1,643.00
-
रo 1,440.00
- Price in reward points:1711
-
- 15 or more रo 1,629.00
- 40 or more रo 1,622.00
- 80 or more रo 1,615.00
