Handheld LCR-Meter H-530 to measure inductance, capacitance & resistance.

Features
  • New type holster, streamline design.
  • Large LCD makes the reading clearly.
  • Metallic screen board with stronger antimagnetic and anti-interferential function.
  • Buzzer alarm, data hold, Diode and Transistor test function.

Specification:

Display 3½ Digit
Inductance Range 20mH - 20H
Inductance Accuracy ± (2.5 % rdg + 25 digits)
Capacitance Range 2000pF - 200µF
Capacitance Accuracy ± (2.5 % rdg + 30 digits)
Dimensions 143x75x32 mm
Power 9 V (6F22)
Weight 200 g
Function hFE (PNP or NPN) Provided, Back light & AUTO POWER OFF
Model No V 5300 M
Resistance Range (Ohm) 20Ω-2000MΩ

Note: Image shown is for representation purpose only. Actual may vary

Write a review

Please login or register to review

LCR Meter - V5300M

  • Product Code:SP-H-530-LCR-Meter
  • Reward Points:15
  • Availability:In Stock
  • रo 1,585.00
  • रo 1,555.00

  • Price in reward points:1450
